Single Mode 1×64 SM Fiber Optic Splitter Fiber Optic Coupler

Model Number : FBT LC

Certification : CE/ROHS/ISO9001

Place of Origin : China

MOQ : 2pcs

Price : CE/ROHS/ISO9001

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 10000pcs per week

Delivery Time : 4-6working days

Packaging Details : Neutral packing

Model : FBT

Connector : LC

Input&output : 1x64

Fiber mode : Single mode

Cable color : Yellow

Contact Now

Optical FBT 1×64 Splitter/Coupler Single Mode With Plastic Box LC Connectors 2mm 3mm

Introduction:

Optical coupler is an optical device that combines or splits power from optical fibers. Optical splitter divides light from a single fiber into two or more fiber channels.

Compliance :

Telcordia GR-1209-CORE

Telcordia GR-1221-CORE

RoHS

Features:

Low Insertion loss

Low PDL

Compact Design

Good channel-to-channel uniformity

Wide Operating Wavelength:1310/1490/1550

Wide Operating Temperature:From -40°C to 85°C

High Reliability and Stability

Application:

FTTX Systems

PON Networks

CATV Links

Optical Signal Distribution

Specifications

1×N FBT Splitter

Parameters	1×2	1×4	1×8	1×16	1×32
Operating Wavelength (nm)	1310/1490/1550
Fiber Type	G657A1 or customer specified
Insertion Loss (dB)(P/S Grade)	3.8/4.0	7.1/7.3	10.2/10.5	13.5/13.7	17/17.4
Loss Uniformity (dB)	0.4	0.6	0.8	1.2	1.5
Polarization Dependent Loss(dB)	0.2	0.2	0.2	0.25	0.3
Return Loss (dB) (P/S Grade)	55/50	55/50	55/50	55/50	55/50
Directivity (dB)	55	55	55	55	55
Wavelength Dependent Loss (dB)	0.3	0.3	0.3	0.5	0.5
Temperature Stability (-40~85 °C)(dB)	0.4	0.4	0.4	0.5	0.5
Operating Temperature (°C)	-40~85
Storage Temperature (°C)	-40~85
Device Dimension (mm)	40×4×4	40×4×4	40×4×4	50×4×4	50×7×4
Module Dimension (mm)	100×80×10	100×80×10	100×80×10	120×80×18	140×115×18
Mini-Module Dimension (mm)	50×7×4	50×7×4	50×7×4	60×12×4	80×20×6

Image:
